Perfect surface in one step
Versatile and efficient processing of all metal parts
Perfect surface in 1 minute
Versatile and efficient processing of all metal parts
Part processing result
Swirler developed by JSC «UEC-Aviadvigatel»
Improving production efficiency
Aimed at the following industries:
Engine building
Instrumentation
Power
engineering
engineering
Additive manufacturing
Medical
appliances
appliances
Aviation
Dental prosthetics and implantation
Car industry
Petroleum engineering
Shipbuilding
Jewelry
production
production
By our method, a workpiece is processed by electric discharge in a vapor-gas envelope surrounding the processed item
How does it work
Echolyte equipment is used for surface treatment of products as an alternative to sandblasting, chemical or electrochemical processing.
The greatest benefits of Echolyte appear when processing products with complex surface profiles, for which alternative methods are ineffective.
This technology generates electric discharge in a vapor-gas medium between a metal anode (workpiece) and cathode (tank).
High temperature of discharge provokes partial destruction, partial anodic dissolution and partial melting of surface micro-irregularities.
This process is selective: peak elevations are exposed to much higher discharge than smooth areas of the anode surface.
The process allows smoothing of the irregularities and improving the quality of surface processing.
Electric current flows through this system, and the electrolyte boils up, forming a vapor-gas shell (plasma) on the anode surface, where the current density reaches its maximum.
The resulting increase in the electric field strength near the local surface irregularities intensifies the process of material removal from these irregularities.
1
Speed
Products become smooth and shiny in a few minutes and they are protected against corrosion and other exposures
Advantages
of Echolyte
of Echolyte
2
Efficiency
Roughness increase up to 5 classes
3
Versatility
Ability to process complex parts with different ridges, internal surfaces and holes
4
Cost effectiveness
Electrolyte is prepared using inexpensive and available materials that do not require special disposal conditions, which significantly reduces operating costs
5
Environmental friendliness
The technology uses no hazardous reagents and thus reduces the impact on human health and the environment, and decreases the disposal costs
6
Performance
The technology is several times more productive than traditional polishing methods, since a series of processes take place during one stage of immersing a part in the tank
7
Modularity
The device can be configured as per customer's requirements
Equipment catalog
Service catalog
Cleaning the surface from abrasive inclusions
Removing such welding effects as oxidation tints
Processing of internal surfaces and channels
Improving surface roughness up to 5 classes
Developing electrolyte formulation and processing modes
Removing burrs in hard-to-reach places
Cleaning the surface from deposits or residue
Preparing products for coating
Calculate the cost of Echolyte
equipment
equipment
Echolyte
Manufacturer of high-tech equipment
for finishing metal parts.
for finishing metal parts.
of experience in additive technologies
10 years
patents
5
experience of electrolytic plasma processing
8 years'
2
know-how
15+
processed materials
Project team
Mikhail Artyushkov
CEO
13 years' experience in project management of varying complexity.
11 years' experience in sales and commercialization
11 years' experience in sales and commercialization
Alexey Kurchev
CTO
11 years' experience in project management.
Work Supervisor and Member of the administrative group for comprehensive AT projects for JSC "UEC-Aviadvigatel"
Work Supervisor and Member of the administrative group for comprehensive AT projects for JSC "UEC-Aviadvigatel"
Chief Designer
Konstantin Nagullin
Doctor of Physical and Mathematical Sciences, Leading Scientist of the Department of Laser Technologies KNRTU–KAI, FSBEI. More than 20 years of experience in R&D implementation
Albert Gilmutdinov
Mentor
Aide to the President of Tatarstan
CMO
Scientific Adviser
Vseslav Davydov
Almaz Gaysin
Marketing and Finance Specialist. 13 years' experience in sales and project management
Sergey Kuzmin
Doctor of Technical Sciences. Head of Technical Physics Department KNRTU–KAI, FSBEI, author of 24 articles reviewed by the Higher Attestation Commission
Project partner
Partners
The development was carried out with the financial support of the FASIE
Order test processing
Our employees are ready to provide you with services for processing of metal parts. Electrolytes and processing modes are selected on an individual basis, depending on your requirements. For more details, please leave a request.
F.A.Q.
The maximum power of the installation does not exceed 150 kW. The power required for processing is determined by the mode, dimensions and material of the product. It is possible to reduce the capacity of the installation for the tasks of the customer
The maximum machining area is limited by the surface area of the submerged part.
Characteristics of the processed parts:
1. Weight - up to 30 kg
2. Dimensions of the part:
- full immersion 600x300x200 mm
For the needs of the Customer, the size of the bath can be changed
Characteristics of the processed parts:
1. Weight - up to 30 kg
2. Dimensions of the part:
- full immersion 600x300x200 mm
For the needs of the Customer, the size of the bath can be changed
After the product is immersed in the electrolyte bath, the bath is covered with a protective shield to minimize the spread of gases and vapors. Gas removal is carried out through a gas and dust removal system, which is connected to a stationary exhaust system.
In addition to the traditional cavitation effects, which intensify the treatment processes, ultrasonic action causes a sonocapillary effect, which promotes deeper penetration of the electrolyte and discharge into the internal cavities of the product. The use of ultrasound makes it possible to ensure uniform metal removal on all surfaces, as well as to increase the processing speed (depending on the class of the material).
Automated blasting is currently in the pre-release stage. The directional jet as a liquid flow electrode effectively treats internal cavities and channels. The processing diameter depends on the diameter of the nozzle. The minimum nozzle diameter is currently 1 mm. In the test mode, the possibility of processing even deaf channels was confirmed. The processing depth is increased due to the intensification of the capillary effect. Blasting is programmable, the control panel provides the ability to set the desired processing mode (time, current power). Work is underway to set the flow rate of the jet.
The Echolyte installation, like the classic electrolytic polishing, provides local surface polishing while maintaining geometric dimensions. Fundamental differences from traditional EPP technology are high processing speed, environmentally friendly electrolyte, processing of internal channels and surfaces, surface improvement up to 5 classes, process automation.
The main differences between plasma electrolytic polishing and vibratory grinder are as follows:
1) The working substance is an electrolyte liquid, therefore, the method allows you to polish the internal channels and non-standard parts;
2) Also, this is not a mechanical method of polishing, so there is no residual stress after processing;
3) Last but not least, the electrolyte is environmentally friendly and can be disposed of without special measures.
1) The working substance is an electrolyte liquid, therefore, the method allows you to polish the internal channels and non-standard parts;
2) Also, this is not a mechanical method of polishing, so there is no residual stress after processing;
3) Last but not least, the electrolyte is environmentally friendly and can be disposed of without special measures.
A prerequisite for processing a part is the conductivity of the material. This Echolyte technology is used for machining tool steel and stainless steel. Silver parts are currently being processed in test mode.
We manufacture and sell Echolyte plants and provide processing services.
We are ready to carry out a test polishing within the framework of possible cooperation. Prerequisites - send at least 3 samples with exact material class (e.g. 316 SST or material composition). This information is essential for the correct selection of the operating mode.
